Video: ESTUN servo drive in position control mode (Part 3)

ESTUN is a leading developer of high-tech automotive components, industrial robotics and advanced manufacturing systems in China. The company has gained its biggest clout in developing Servo drive products motors, controllers and drivers.

Position control mode is one of the most used control modes for servo drives. In this mode drive all the time follows servo motor position and compares real position to sent position. The servo motor is controlled by the PLC controller, the servo drive can be freely configured and adapted to different machines.

The video guide shows the following functions:

• Disabling P-OT, N-OT, S-ON signals
• Setting the position control mode
• Selecting a reference pulse shape
• Electric gear configuration
